Detailed Description

The device driver for the CS8900A is poorly supported. Be prepared that some debugging may be required when using it with the latest Nut/Net release.


Data Structures
struct	_NICINFO
	Network interface controller information structure. More...
struct	_NICINFO
	Network interface controller information structure. More...
Typedefs
typedef _NICINFO	NICINFO
	Network interface controller information type.
Functions
void	CSWrite16 (u_short addr, u_short data)
void	CSWritePP16 (u_short addr, u_short data)
u_short	CSRead16 (u_short addr)
u_short	CSReadPP16 (u_short addr)
u_long	CSReadPP32 (u_int addr)
void	CSBeginFrame (void)
void	CSEndFrame (void)
void	CSWriteFrameByte (u_char data)
int	CSNicOutput (NUTDEVICE dev, NETBUF nb)
	Send Ethernet packet.
void	CSNICrx (void *arg)
	NIC receiver thread.
void	CSSoftwareWakeup (void)
void	CSSoftwareReset (void)
int	CSNicInit (NUTDEVICE *dev)
	Initialize Ethernet Interface.
void	CSWrite16 (u_long addr, u_short data)
u_short	CSRead16 (u_long addr)
int	cs8900Output (NUTDEVICE dev, NETBUF nb)
	Send Ethernet packet.
int	cs8900Init (NUTDEVICE *dev)
	Initialize Ethernet hardware.
Variables
u_char	cs_flags
volatile u_short	cs_base = 0x0000
volatile u_long	cs_base = 0x82000000UL
NUTDEVICE	devCS8900A
	Device information structure.

Function Documentation

int CSNicOutput	(	NUTDEVICE *	dev,
		NETBUF *	nb
	)

Send Ethernet packet.

Parameters:

	dev	Identifies the device to use.
	nb	Network buffer structure containing the packet to be sent. The structure must have been allocated by a previous call NutNetBufAlloc(). This buffer will be automatically released in case of an error.

Returns:: 0 on success, -1 in case of any errors. Errors will automatically release the network buffer structure.

void CSNICrx

(

void *

arg

)

NIC receiver thread.

It runs with high priority.

int CSNicInit

(

NUTDEVICE *

dev

)

Initialize Ethernet Interface.

Applications typically do not use this function, but call NutNetIfConfig().

Parameters:

dev

Identifies the device to initialize. The structure must be properly set.

int cs8900Output	(	NUTDEVICE *	dev,
		NETBUF *	nb
	)

Send Ethernet packet.

Parameters:

	dev	Identifies the device to use.
	nb	Network buffer structure containing the packet to be sent. The structure must have been allocated by a previous call NutNetBufAlloc().

Returns:: 0 on success, -1 in case of any errors.

int cs8900Init

(

NUTDEVICE *

dev

)

Initialize Ethernet hardware.

Resets the CS8900 Ethernet controller, initializes all required hardware registers and starts a background thread for incoming Ethernet traffic.

Applications should do not directly call this function. It is automatically executed during during device registration by NutRegisterDevice().

If the network configuration hasn't been set by the application before registering the specified device, this function will call NutNetLoadConfig() to get the MAC address.

Parameters:

dev

Identifies the device to initialize.

Variable Documentation

NUTDEVICE devCS8900A

Initial value:

 {
    0,
    {'e', 't', 'h', '0', 0, 0, 0, 0, 0},
    IFTYP_NET,
    0,
    0,
    &ifn_eth0,
    &dcb_eth0,
    cs8900Init,
    0,
    0,
    0,
    0,
    0,
    0
}

Device information structure.

A pointer to this structure must be passed to NutRegisterDevice() to bind this Ethernet device driver to the Nut/OS kernel. An application may then call NutNetIfConfig() with the name eth0 of this driver to initialize the network interface.
